HV Stackable
Energy Storage Battery
The BS06-S series delivers high-voltage, high-density residential energy storage designed for safety and efficiency. Featuring a flexible, stackable architecture with 100Ah premium cells, it offers modular capacity from 15.36 kWh up to 46.08 kWh to match any household backup requirement.
15.36 – 46.08 kWh
Up to 5 Per Parallel
Core Technical Advantages
Higher Density, Fewer Packs
Features 53.6% higher energy density compared to traditional systems, minimizing physical footprint while maximizing power availability.
Intelligent Design
Bluetooth & Wi-Fi enabled system allowing direct real-time APP monitoring, paired with seamless OTA remote firmware upgrade capabilities.
Tip-resistant Fixation
Engineered with physical inter-module locking pins/fasteners and rear wall-mounted anchor points to guarantee rock-solid structural stability.
Snap-Fit Stacking
Consolidated from a dual-stack to a clean single-stack design, utilizing rapid snap-fit connections with scalable capacity up to 6-module stacks.
High Safety Performance
Built with integrated physical grounding points and advanced cell-level and pack-level safety safeguards to maximize user protection.
Smart & High-Efficiency
Features high-efficiency operations enhanced by adaptive self-learning SOC/SOH algorithms and proactive, autonomous fault diagnostics.
I. Model Performance Specifications
| Parameter | BS06-15-S/2S | BS06-23-S/3S | BS06-30-S/4S | BS06-38-S/5S | BS06-46-S/6S |
|---|---|---|---|---|---|
| Nominal Energy | 15.36 kWh | 23.04 kWh | 30.72 kWh | 38.40 kWh | 46.08 kWh |
| Usable Energy (90% DOD) | 13.82 kWh | 20.73 kWh | 27.64 kWh | 34.56 kWh | 41.47 kWh |
| Nominal Voltage | 153.6 V | 230.4 V | 307.2 V | 384.0 V | 460.8 V |
| Voltage Range | 134.4 ~ 172.8 V | 201.6 ~ 259.2 V | 268.8 ~ 345.6 V | 336.0 ~ 432.0 V | 403.2 ~ 518.4 V |
| System Weight | 184 kg | 259 kg | 334 kg | 409 kg | 484 kg |
| Dimensions (W*D*H) | 870*450*530 mm | 870*450*690 mm | 870*450*850 mm | 870*450*1010 mm | 870*450*1170 mm |
| Cumulative Discharge | 24.6 MWh | 37.0 MWh | 49.3 MWh | 61.6 MWh | 74.0 MWh |
II. Battery System Core Specifications
III. Mechanical & Environmental
IV. Security & Certification
Product Excellence in Detail
