Model: ESS1000-2089 / ESS500-1045
C&I Energy Storage System
A high-capacity containerized solution (20GP/40GP) designed for large-scale commercial and industrial applications, featuring up to 2.089MWh capacity, intelligent thermal management, and C5 anti-corrosion protection.
Energy Capacity
Up to 2.089 MWh
Up to 2.089 MWh
Cycle Life
≥8000 Cycles
≥8000 Cycles
⚡ Multi-Mode Flexibility
Multiple working modes can be flexibly set to meet various energy demands.
📊 Real-Time Status Monitoring
Support real-time online monitoring of system status and performance analytics.
🌡️ Intelligent Thermal Control
Advanced BMS and comprehensive thermal management for optimized battery life.
🔌 Universal Power Access
Support simultaneous access to load, battery, grid, and Diesel Generator (DG).
I. Performance Specifications (AC Data)
RATED POWER1000 / 500 kW
RATED VOLTAGE400 V
RATED CURRENT1570A / 785A
VOLTAGE RANGE320V – 460V (On-grid)
RATED FREQUENCY50 / 60 Hz
THDi (ON-GRID)< 3%
POWER FACTOR1 (0.8 leading ~ 0.8 lagging)
AC OUTPUT3W+N+PE
OFF-GRID SWITCHINGSupport
OVERLOAD CAPACITY110% Long term
II. Battery Specifications
CELL TYPE3.2V / 314Ah
NOMINAL VOLTAGE665.6 V
NOMINAL ENERGY2.089 / 1.045 MWh
VOLTAGE RANGE582.4 – 748.8 V
MAX. C RATE0.5C @ 25°C
CYCLE LIFE≥ 8000
III. System & Mechanical Data
DIMENSIONS (W*D*H)40GP / 20GP Container
NET WEIGHT38,000 / 21,000 kg
INGRESS PROTECTIONIP54
OPERATING TEMP0 ~ +45°C
ALTITUDE3,000 m
FIRE SYSTEMFM200 / NOVEC1230
DISPLAYTouch LCD + Cloud
CORROSION GRADEC5
