I. Performance Specifications
BATTERY TYPELiFePO4
NOMINAL VOLTAGE51.2 V
CONFIGURATION3.2V314Ah/16S1P
CAPACITY314 Ah
NOMINAL ENERGY16.08 kWh
USABLE ENERGY14.47 kWh (@80%DOD)
MAX. CURRENT150 A
VOLTAGE RANGE44.8V ~ 57.6V
SCALABILITYUp to 15 units
COMMUNICATIONCAN; RS485
WARRANTY5 + 5 Years
DISCHARGE ENERGY25.8 MWh
II. Security & Mechanical
WEIGHT127 kg
DIMENSION460*245*800 mm
IP RATINGIP54
INSTALLATIONWall / Ground
III. Environmental Specifications
OPERATING TEMP-20~55°C
ALTITUDE≤ 2000 m
HUMIDITY≤ 90%
PROTECTIONIntegrated BMS
Technical Parameters
